154.154.00.1
ID: 3357Geberit CleanLine Shower Channel Trap Waste 154.154.00.1
- fastening material inclued
- high quality manufacture
- open outlet
- square design
Other Shower Waste You May Like Instead...
Geberit CleanLine Shower Channel Trap Waste 154.154.00.1
Geberit CleanLine Shower Channel Trap Waste
The CleanLine Shower Channel Waste from Geberit is an innovative and easy to install shower channel waste.
It features an open outlet surface which means no concealed build-up of deposits and a sealing foil injected at the factory.
This is firmly connected to the drain and ensures maximum tightness.
Designed to be used in conjunction with CleanLine Shower Channels.
Features:
- Quality-monitored in accordance with EN 1253-3
- Minimum screed height at inlet 90 mm
- Sealing fleece, pre-mounted, 10 cm circumferential, for connecting sealing systems
- Base unit made of EPS, for sound decoupling and receiving the trap
- Discharge rate 0.8 l/s
- Depth of water seal 50 mm
- Protection box cover with reference line
- Thin bed bonding flange
- Trap made of PE-HD
- Adaptor ø 50 mm to G 2 (ø 55 mm)
- Fastening material
Product Specification
Length_(mm) | 390 |
Width_(mm) | 192 |
Height_(mm) | 213 |
Brand | Geberit |
Product Guarantee | 1 Year |
